Caterclad®
Caterclad®
Developed in conjunction with Senior Environmental Health Officers, Caterclad® is the wall finish you can be sure is proven safe and hygienic, where it counts the most – where food is prepared or provided. That is why Caterclad® is a popular choice in hotels and restaurants, schools, hospitals and food processing plants.
Caterclad® conforms to EU and UK requirements in respect of wall finishes in food environments. Caterclad® is the only PVC hygienic wall lining system that has the EU Reports PrEN 13823 exposure to thermal attack and PrEN ISO 11925-2: 1999 direct impingement of flame.
Caterclad® has Warrington Fire Research Centre Reports confirming a pass in both BS476 Part 6 – Fire Propagation – and BS476 Part 7 – Surface Spread of Flame. Caterclad® also complies with Paragraph A12(b) of Approved Document B, Fire Safety in Building Regulations 1991.
The impervious finish only requires a wash down with hot water and sanitiser for it to be hygienic, clean and at the same time retain appearance
Technical Specification
| Sheet dimensions | 2500 X 1220 x 2.5mm and 3050 X 1220 x 2.5mm |
| Surface spread of flame | BS476 Part 7 1997 Class 1 |
| Impact strength izod notch hardness | 2.1 |
| Co-efficient of thermal expansion | 3.7 x 10-5 |
| Specific gravity | 1.4 |
| Thermal conductivity | 1.05 |
| Maximum service temperature | 65°C |
| Elastic modulus at bend | 4.5 x 10-3 |
| Colour | Matt White |
Caterclad® Certification
PrEN 13823 exposure to thermal attack – Warres 116582 (EU Test)
PrEN ISO 11925-2 1999 direct impingement of flame – Warres 116603 (EU Test)
BS 476: Part 7: 1997 Surface Spread of Flame Class 1 Warres 102778
BS 476: Part 6: 1989 Fire Propagation Pass Warres 102779
Compliance as defined in Paragraph A12(b) of Approved
Document B, ‘Fire Safety’ in Buildings Regulations 1991
EEC Commission Directive 90/128/EEC Food Contact Safe Plastic
SGS Certification CP43044/BW/98
Lloyds Register of Shipping Certification SAS F020203/A1 for Marine & Off-Shore use
Architectural Specification
Supply and install Caterclad® to a finished height or Colour Match heat welded joints using Cladfix® panel adhesive; thermoformed internal and external corners with Cladfix® Co-extrusions between panels. Provide an Interclad® Assurance on completion.
| Caterclad®/Mediclad® | m2 |
| Caterclad®/Mediclad® (less than 300mm) | m |
| Thermoformed internal/external corners | m |
| Waterproof sealant at abutments | m |
| Cutouts for service | No |
Standard Trims
Panel Joint (H) 2.5m/3.0m
End Stop (J) 2.5m/3.0m
External Corner (F) 2.5m/3.0m
Modified Panel Joint 2.5m only
Standard Trim Dimensions
Panel Joint (H)
End Stop (J)
External Corner (F)
